The LAN Power Model LP-2104 Four (4) Port PoE Midspan Desktop Injector supports powering up to Four (4) IP 'PoE Enabled' End Devices. The Four (4) Port PoE Midspan Injector adds up to 35 watts continuously per port at ~48 VDC wires in a standard Category 5, 5e, or 6 Ethernet cable.
Output Wattage is up to 35 Watts continuously out each of its eight ports-power up to 8 IP Devices Cost Effective Compliant to IEEE 802.3at Power over Ethernet Standards Supports Data links at 10Mbs or 100Mbs or 1000Mbs (Gigabit Compatible) Extended Temperature operating range LED indicators shows powering status Surge Protection with over voltage current and short circuit protected (protects the Ethernet Switch) Data and Power carried on same Ethernet cable
| Installation Instructions | Download here |
| Product Sheet | Download here |
